Solving your CO2 pipeline challenges with industry-leading simulation technology

As a pipeline engineer or control room operator, you face unprecedented challenges in CO2 transport operations. The thermodynamic complexities of gaseous, dense-phase or super critical CO2, stringent regulatory requirements, and critical safety considerations demand specialized solutions.

DNV's Synergi Pipeline Simulator leverages our 40+ years of expertise with CCUS projects to help you navigate these challenges with confidence.

Solutions for every stage of CO2 pipeline operations

Design with confidence, operate with safety

Pipeline Simulator’s advanced Surge Analysis capabilities provide critical insights into pipeline behavior under various operating conditions, eliminating the guesswork and giving you confidence during critical design decisions and operational changes.

Key capabilities include:

  • Phase management: Maintain CO2 operations in the intended phase by monitoring pressure, temperature, and vapor pressure or dew point pressure
  • Pressure surge protection: Identify surge pressure or water hammer impact
  • Mitigation measures: Verify surge mitigation measures, ensure safe startup and shutdown operations, particularly during emergency scenarios
  • Environmental impacts: Study the environmental thermal effects that could impact phase management. Also, calculate fuel consumption and estimate emissions
  • Network planning: Evaluate optimal size and location of valves, regulators, pumps and compressors
  • Repurposing pipelines: Develop strategic, operational and capacity planning

Synergi Pipeline Simulator performs comprehensive surge analysis, including valve closures, pump starts/trips, and bubble formation/collapse - ensuring your CO2 pipeline operations remain safe and efficient throughout their lifecycle.

Real-Time operational excellence

Control room operators need continuous, accurate information to maintain optimal CO2 pipeline performance. Synergi Pipeline Simulator's Statefinder module provides real-time decision support, leveraging proprietary state estimation technology, enabling operators to monitor and adjust CO2 operations in real-time.

Critical real-time capabilities include:

  • Phase transition monitoring: Track how close your system is to vapour pressure or dew point pressure thresholds
  • Impurity tracking: Monitor full gas composition and contaminants throughout your pipeline system
  • Linepack management: Optimize throughput while maintaining safe operating conditions
  • Anomaly detection: Identify and address operational deviations quickly
  • Temperature monitoring: Prevent brittle fracture and other temperature-related failures

Statefinder integrates seamlessly with your existing SCADA systems, automatically adjusting to changing CO2 compositions without requiring manual intervention.

Reliable pipeline leak detection technology

Synergi Pipeline Simulator's Leakfinder module employs advanced state estimation technology, enabling reliable detection even with imperfect operational data. It pinpoints leak positions and dramatically reduces response times and remediation costs.

Control room operators benefit from:

  • RTTM-based monitoring: Gain more detailed monitoring capabilities and insights than traditional metering systems
  • Advanced leak detection: Utilizes real-time SCADA data to identify inconsistencies, including potential leaks
  • Pattern recognition: Identify leak signatures even when working with imperfect operational data
  • Leak location: Pinpoint leak positions , reducing response times and remediation costs

Leakfinder's early detection capabilities alert control room operators to anomalies from the earliest onset -when intervention is most effective and least expensive.

Prepare for CO2-specific operational scenarios in a risk-free environment

The transition to CO2 pipeline operations introduces operational scenarios that even experienced hydrocarbon pipeline operators haven't encountered. Our Trainer and Operator Qualification Management (OQM) modules provide your team with a realistic simulation environment to develop critical CO2-specific expertise without the consequences of operational mistakes.

  • Rapid response training: Prepare control room operators to react within seconds to abnormal events like pump trips, stuck valves, pigging anomalies or leaks
  • Phase change management: Develop expertise in maintaining optimal CO2 phase conditions
  • Incident response: Train control room operators on CO2-specific emergency protocols, accounting for its unique dispersion characteristics
  • Regulatory compliance: Generate documentation for operator certification requirements
  • Performance tracking: Verify competency through comprehensive assessment tools

Trainer and OQM help create a robust safety culture while ensuring all personnel are qualified for the specialized demands of CO2 pipeline operations.

Optimizing operations through multiple scenario testing

Synergi Pipeline Simulator's Model Lab enables in-depth parametric studies to enhance decision-making through simulation. It helps identify feasible solutions and pinpoint optimal network performance, leading to safer CO2 operations and reduced expenditures.

  • Energy efficiency analysis: Identify scenarios that maintain dense phase while minimizing pumping energy requirements
  • Scenario planning: Identify operational windows for safe performance
  • Adaptation support: Test incremental changes when switching to CO2 or modifying operations
  • Seasonal variation modeling: Understand how your CO2 system performs across different environmental conditions
  • Composition response: Verify system behavior with changing inlet CO2 compositions
  • EoS comparisons: Evaluate sensitivity using different equations of state
  • Faster tuning: Automated repeatable tuning for improved simulation of soil temperatures, DRA or instrument sensitivity

Each simulation helps identify optimal solutions for your network, leading to safer CO2 operations and reduced operational expenditures.

Why leading CO2 pipeline operators choose Synergi Pipeline Simulator

DNV's specialized expertise is delivered through Synergi Pipeline Simulator to address the unique challenges you face daily in CO2 transport operations.

  • Specialized Expertise: Purpose-built tools from design through operations
  • Proven Performance: Over 40 years of experience supporting CCUS projects worldwide
  • Continuous Innovation: Regular updates incorporating the latest research findings
  • World-Class Support: Access to pipeline modeling experts with CO2-specific experience
