Automated Design - Synergi Gas

Optimize network efficiency

The Automated Design module is a software tool that enables you to optimize network efficiency and keep costs down by assessing pipe size options for your model with specified loading conditions, material and installation cost and location.

What you get with the Automated Design module

Useful in designing new systems or expanding and reconstructing existing networks
Enables optimized network efficiency
Determines low-cost design for new service areas or major mains replacement efforts
Clearly identifies incremental cost by designing to a higher minimum pressure

Automated Design for gas networks

With Automated Design you can find the lowest possible pipe diameter capable of transporting sufficient quantities of gas to required delivery points safely and reliably.

Quickly analyses system design and avoids over-design
Operates in single-pressure level networks on data and criteria you provide
Pipe installation parameters include internal diameter, material type and installation cost per unit length

Explore more Synergi Gas modules:

Model Builder

The Model Builder module in Synergi Gas provides seamless integration with your GIS data and streamlines the process of building and maintaining Synergi Gas models by automating data import, converting GIS point data into linear facilities, and mapping source attributes to model data, thereby enhancing model efficiency and reducing maintenance time.

Unsteady-State Module

The Unsteady-State module in Synergi Gas is a powerful tool for transient analysis, enabling you to manage linepack, simulate line breaks, gas blowdowns, and other dynamic events in gas networks. It allows for the modeling of complex pipeline systems, including compressors and storage fields, and simulates changes in gas composition and network conditions over time, facilitating volumetric or thermal balancing and the operation of facilities during simulations.

Customer Management Module

Customer Management Module in Synergi Gas integrates with your Customer Information System (or customer billing system) to calculate temperature-dependent and base load factors, assigns these loads to the model, and enables display of customer information in the model.

Area Isolation Module

The Area Isolation module in Synergi Gas assesses the hydraulic impact of emergency or planned outages. It is used for emergency planning, maintenance, and other operational needs, allowing users to analyze the impact of isolation on network pressure and flow, generate detailed reports, and identify affected customers, all within a user-friendly interface.

Time-Varying Module

The Synergi Gas Time-Varying module performs a series of consecutive steady-state analyses to simulate changes in gas networks over time. It allows for long range planning of storage/gathering systems, link simulations for tasks like inventory tracking and maintenance scheduling, and determine system adequacy and fuel requirements, making it suitable for various gas systems.

Regulator Station Module

The Regulator Station module in Synergi Gas is designed to protect distribution systems from overpressure conditions. It supports monitoring and reporting on safety equipment, ensuring compliance with regulations, and offers features such as an extensive equipment catalogue, analysis of relief valve piping, and generation of detailed station reports to enhance safety and reliability while reducing maintenance efforts.

Optimization Module

The Optimization module, or Optimizer, in Synergi Gas is designed to optimize fuel consumption and costs for gas transmission pipelines. It analyzes pipeline throughput, identifies bottlenecks, and optimizes compressor operations to maximize system throughput or minimize fuel costs.

Facilities Management Module

The Facilities Management module in Synergi Gas synchronizes gas distribution network models with GIS updates without requiring a full rebuild. It allows users to compare models, review changes spatially, and selectively integrate updates, streamlining maintenance tasks and enhancing model management flexibility.

Learn more about Synergi Gas software

Have a look at our brochure, videos and other information
